Overview
Central transmission thickener clarifier is a new type of center drive, automatic harrow lifting and falling harrow thickener developed by our company.
Application
It is widely used in concentrating various industrial slurries, such as metal beneficiation raw ore, concentrate, tailings slurry; coal washing slurry in coal preparation plant, chemical slurry,
Structure
1.Tank: a sealed container used to hold liquids or slurries to be processed.
2.Rake frame: A rake frame fixed at the center of the concentration tank, used to scrape and collect sediment.
3.Transmission device: usually composed of a motor and a reducer, it drives the rake frame to rotate.
4.Lifting device for rake frame: When the torque is too high, the rake frame can be manually or electrically lifted to prevent equipment damage.
5.Feeding device: Feed the raw materials into the concentration tank.
6.Unloading device: discharge the processed material.
7.Signal safety device: ensuring the safe operation of equipment
-
Working principle
1. Central transmission thickener is to uniformly rotate the liquid or slurry in the container through the central transmission device, and to separate the volatile components such as solvents and water in the liquid through heating and vacuum extraction, thereby achieving liquid concentration.
2. During the operation, the sludge is collected by a scraper into the central collection tank through deceleration drive and transmission of suspended components, and discharged outside the tank by static water pressure or pump. Adopting middle water inlet and sludge discharge, and surrounding drainage to ensure uniform water flow.
3. Self suction sludge discharge using liquid level difference, equipped with floating slag scraping and removal device and overload protection device
-
Features & Benefits
The advantages of hydraulic Central transmission thickener mainly includes the following aspects:
Large processing capacity, energy consumption, investment cost, maintenance convenience, overload protection, automation control, etc
1.Large processing capacity:
The processing capacity of hydraulic center transmission concentrator is significantly higher than that of ordinary concentrator, and its processing capacity can reach 4-9 times that of ordinary concentrator, especially suitable for scenarios with large tailings concentration operations.
2.High concentration efficiency:
Has low energy consumption during operation, and by adding flocculants, it can achieve high concentration bottom flow, thereby saving costs.3. Low investment cost:
The same specifications save about 30% in infrastructure investment compared to ordinary thickeners.4. Easy maintenance:
Due to the use of an adjustable structural design, the maintenance of the hydraulic center transmission concentrator is very convenient. The scraper or rake can be separately lifted for maintenance and replacement, reducing downtime and maintenance costs.5. Reliable overload protection:
The equipment is equipped with a PLC automatic sensing pressure sensor. When the scraping device is overloaded, it will automatically lift the rake frame, reduce the load, and ensure the safe operation of the equipment.6. High degree of automation:
Can automatically adjust the discharge concentration according to the bottom flow concentration, ensuring stable bottom flow concentration and reducing solid particles in overflow.7. Structural optimization:
Driven by a hydraulic motor, which drives the slewing support through gears. The transmission shaft drives the rake frame to rotate. This design allows for larger equipment specifications and more reliable overload protection.8. Efficient and stable:
The equipment is designed reasonably, runs smoothly, has high efficiency, and reduces maintenance costs. -
Specifications
Item Model Diameter(m) Center depth(mm) Sedimentation area (㎡) Rotating speed(min/r) Lifting height(mm) Capacity(m³/h) Oil pump power motor Rake cylinder Power(kw) 1 NXZ-6 φ6 3100 28 2.5-5 350 50-100 10SCY-112M-4 HGS63/50 4 2 NXZ-9 φ9 3957 69 5-10 500 100-200 10SCY-112M-4 HGS63/50 4 3 NXZ-12 φ12 4365 113 5-10 500 300-400 10SCY-112M-4 HGS63/50 5.5 4 NXZ-15 φ15 4551 176 5-10 500 400-600 25SCY-132M-4 HGS63/50 7.5 5 NXZ-18 φ18 5304 250 4-15 500 650-900 25SCY-132M-4 HGS63/50 7.5 6 NXZ-24 φ24 5533 460 5-20 500 1000-1500 25SCY-132M-4 HGS63/50 7.5 7 NXZ-30 φ30 6790 706 10-22 500 1500-2000 25SCY-132M-4 HGS63/50 7.5+4 8 NXZ-38 φ38 5079 1133 12-30 600 2000-2500 40SCY-160M-4 HGS140/50 11+4 9 NXZ-45 φ45 5079 1590 14-30 600 2400-3000 40SCY-160M-4 HGS140/50 11+5.5 10 NXZ-53 φ53 7517 2206 17-30 600 3000-4000 63SCY-160M-4 HGS160/70 15+5.5 11 NXZ-60 φ60 8439 2826 19-35 600 4000-6000 80SCY-160M-4 HGS160/70 22+7.5 12 NXZ-80 φ80 9385 5026 25-40 600 8000-11000 120SCY-200L-4 HGS180/90 30+7.5 13 NXZ-100 φ100 7853 7853 32-50 800 15000-18000 120SCY-200L-4 HGS180/90 37+11 Related:
