Overview
Mining dryer is a kind of dryer suitable for all kinds of mineral ore,mainly used in metallurgical, mining, chemical and other industries. Its main function is drying minerals with high moisture content , to reduce their moisture content to the expected effect, in order to meet the needs of subsequent processes.
The entire set of drying equipment is reasonably designed and well-made. It is characterized by continuous production, high drying efficiency, fast drying speed and simple operation.
-
Working principle
The commonly used drying method for mineral dryers is through heat transfer.
Mineral materials containing moisture enter the dryer drum through a conveyor and are dispersed in the drum.
With the action of the lifting plate device, the contact area between minerals and high-temperature hot air is increased, causing the moisture content of mineral materials to continuously decrease until the dried material is discharged from the discharge port, achieving the entire process of mineral drying.
There are various options for the heat source in the heat transfer drying process, such as coal, natural gas, biomass pellets, fuel oil, and more.
-
Features & Benefits
1.Efficient and energy-saving: adopting advanced heat exchange technology, high thermal efficiency and low energy consumption.
2.High degree of automation: adopting intelligent electronic control system, simple operation, reducing manual intervention, and improving production efficiency.
3.Good drying effect: By using a special drying process, the moisture content of the iron mud can be quickly reduced to the expected range.
4.Stable and reliable equipment: Using high-quality materials and advanced manufacturing processes, the equipment operates stably and has a long service life.
5.Environmental Protection: The exhaust gas, wastewater, and other pollutants generated by the equipment during operation can be effectively treated, meeting environmental protection requirements.
6.Strong adaptability: The drying parameters can be adjusted according to different properties of iron sludge and drying requirements to meet different drying needs.
-
Specifications
Model Capacity(T/D) Raw Material Moisture(%) Dry Material Moisture(%) Power(kw) Area Occupancy(Width x Length) STKG1918 300±10 25±5 ≤12 109 7m*25m STKG2218 500±10 25±5 ≤12 128 8m*30m STKG2520 700±12 25±5 ≤12 240 8m*30m STKG2822 1000±15 25±5 ≤12 400 8m*40m STKG3024 1200±20 25±5 ≤12 480 12m*50m STKG3428 1500±30 25±5 ≤12 600 12m*60m STKG3830 1800±30 25±5 ≤12 800 16m*70m STKG4032 2000±30 25±5 ≤12 1000 18m*70m STKG4238 2500±30 25±5 ≤12 1200 20m*80m -
