Overview
Compost trommel screen is a device that uses the centrifugal force generated by the rotation of the drum, and the screening effect of the mesh aperture, to grade and remove impurities from fertilizers.
This process not only achieves fine processing of compost, but also effectively removes impurities, improving the purity and efficiency of compost.
What is compost?
Composte is a process of converting organic waste into organic fertilizer, with main raw materials including crop straw, weeds, leaves, organic household waste, kitchen waste, sludge, human and animal manure, etc.
Composte is not only rich in nutrients, but also promotes the formation of soil particle structure, enhances soil water retention, insulation, breathability, and fertilizer retention capacity. It is an environmentally friendly and beneficial way for plant growth
-
Working principle
Compost trommel screen mainly consists of motor, reducer, drum assembly, frame, sealing cover, inlet and outlet, etc.
1. After being fed into the drum, with the slow rotation of the drum, the Compost particles move forward along the inclined angle of the drum and are screened layer by layer under the combined action of gravity and centrifugal force.
2. Larger impurities and particles that do not meet the particle size requirements will be left on top of the upper sieve, while smaller, compliant Composite particles will fall into the collection device below through the sieve.
-
Features & Benefits
1. Efficient screening:
Compost trommel screen achieves screening through the rotation of the drum and the flipping and migration of materials, and can screen a large amount of materials in a short period of time.
2. Easy to operate:
Compost trommel screen has a reasonable structural design, easy maintenance, a large footprint but low energy consumption, and is suitable for handling materials of various properties, including wet and viscous materials.
3. Strong durability:
Made of high-quality materials, wear-resistant and corrosion-resistant, with a long service life, reducing long-term operating costs
-
Specifications
Model Drum diameter(mm) Drum length(mm) Rotary speed(rpm) Dip angle(degree) Power(kw) Dimension(m) Weight(t) ST1.0×3.0 1000 3000 22 2-2.5 1.5 3.5×1.4×2.2 1.5 ST1.2×4.0 1200 4000 16 2-2.5 4 5.2×0.6×2.4 2.3 ST1.5×5.0 1500 5000 14 2-2.5 7.5 6.9×1.9×3.0 3.8 ST1.6×6.0 1600 6000 12 2-2.5 11 7.3×2.0×3.0 4.7 -
